Hydroo SX Submersible Borehole Pump

Vertical multistage pump with water-filled or oiled-filled NEMA standard submersible motor for 4”, 6”, 8” deep well. Non-return valve with each pump.

Impeller & diffuser made of stamping & welding 304 stainless steel.

AISI304 Stainless steel

Applications – Water supply from deep wells and dams, Irrigation, Sprinkling and boosting, Fire-fighting applications, Washing systems,  Mining

Flow range: up to 540 m³/h

Head: up to 450 m

Temperature: up to +50 ºC

Speed: 2900 rpm or 3500 rpm

Power: up to 350 kW

Immersíon depth: up to 300 m

Sizes: 4” to 12”
